RGK750
GEN-SET CONTROLLER AMF 2x EXP.
R12,624.66
Supplier: Lovato Electric
Pack Size: 1
RGK700 automatic mains failure (AMF) gen-set controllers
Features:
- Engine protection
- Programmable alarm properties
- Programmable inputs and outputs
- Supervision in open transition for contactors, motorised circuit breakers and changeover switches
- Automatic starting of generator and load switching to stand-by emergency source in case of mains failure
- RS232 communication port
- Customisable alarm text (2 alarms)
- Customisable alarm text (8 alarms)
- Non-volatile memory for event storage
- Modbus-RTU and Modbus-ASCII protocols
- PLC logic for inputs, outputs and internal status
- With CANbus-J11939 (no W or magnetic pickup)
- Single, two and three phase voltage control L1-L2-L3-N
- NFC technology for parameter setup via smartphone or tablet
- IR programming port on front panel for communication with PC
- Expansion bus with 2 slots for EXP... series expansion modules
- 1 analog resistance input for oil pressure / engine temperature or fuel level control
- 3 analog resistance input for oil pressure, engine temperature or fuel level control
| DIGITAL INPUTS | 6 |
| DIGITAL OUTPUTS | 7 |
| DESCRIPTION | Grey stand alone gen-set controller |
| UNIVERSAL SUPPLY | 12 / 24 VDC |
| DISPLAY | Graphic LCD 128 x 80 pixels with backlight |
| MEASUREMENT VOLTAGE | 30 600 VAC (programmable VT ratio) |
| CURRENT INPUT | 3PH, /5A or /1A |
| OPERATING TEMPERATURE | -30 +70°C |
| MOUNTING | Panel |
| DIMENSIONS (MM) | 180 x 240 |
| EXPANSION MODULES | Up to s slots with EXP... expansion modules |
