NGN101
1A 1P 10KA D-CURVE MCB
R203.40
Supplier: Hager
Supplier Code: NGN101
Pack Size: 1
Miniature circuit breakers (MCB's)
- Protection and control of circuits against overload and short circuits Suitable for domestic and commercial installations.
- Suitable for domestic and commercial installations.
Features:
- Compatible for DC voltage applications
- Accepts clip-on: auxiliaries, shunt trip, undervoltage and earth leakage
- For the protection and control of circuits against overload and short circuits
| SERIES | NGN series |
| CURRENT RATING | 1A |
| NUMBER OF POLES | 1 |
| BREAKING CAPACITY | 10kA |
| DESCRIPTION | Miniature circuit breaker |
| WIDTH IN 17.5MM | 1 |
| CURVE | D (10-20 In) |
| SANS/IEC | 60947-2 / SANS556 |
| APPLICATION | Mainly for motor control/protection |
| RATED OPERATIONAL VOLTAGE | 240/400V |
| FREQUENCY | 50-60Hz |
