GAZS025EM
25A STAINLESS STEEL ENCL ISOLATOR
R3,923.01
Supplier: EM
Supplier Code: GAZS025EM
Pack Size: 1
Stainless steel (AISI 304) enclosed isolators
G... series enclosed switch disconnectors are supplied in robust, heavy duty enclosures in an IP65 execution. The enclosures incorporate a red/yellow operating handle mechanically interlocked with cover in the "ON" position and padlockable (3 padlocks) in the "OFF" position.
| AC-21A ? 690V | 25A |
| AC-23A ? 415V | 11.0kW |
| NUMBER OF POLES | 3 For 4 pole - add attachable switch |
| DESCRIPTION | Stainless steel enclosed load-break GAZ series switch |
| PROTECTION INDEX IP | IP65 |
| DIMENSIONS (MM) | (H) 200 x (W) 150 x (D) 120 |
