DVP40EC00R3

16DI+16DO ECONO PLC TRANSISTOR

R5,101.40
Supplier:

EC3 economic series PLC 100 - 240 VAC

DVP-EC3 series is the most economical solution for sequential control and communication monitoring for smaller applications with simple RS485/MODBUS communication.

Key features:

  • Program capacity: 4k steps
  • Mounting: DIN-rail or chassis mounting
  • High-speed pulse output: Max. 11kHz pulse output
  • MPU I/O points: 10/14/16/24/32/48 points (not expandable)
  • Compact: (H) 90 x (D) 45.5 mm (W) no. I/O point dependant
  • Built-in high-speed counters: 2x 20/10kHz, 1x 20kHz, 1x 4kHz
  • COM ports: Built-in RS232 & RS485 (only for 16/24/32/48 points)
SERIES EC3
SUPPLY100 - 240 VAC
DIGITAL INPUT 24
DIGITAL OUTPUT16
DESCRIPTIONStandard economic PLC
OUTPUT TYPERelay
DIMENSIONS (MM)(H) X 90 X (W) 45.5 X (W) - number of Input/Output point dependent
