383070

125A aM DIN NH00 FUSE LINK 500V

R193.22
Supplier: DF Electric
Pack Size: 1
Stock Availability: Login to check stock

(*) Minimum Quantity: 1

aM (motor protection) fuse links (top indicator)

aM class (NH) for motor protection. These high breaking capacity fuse-links are intended for short circuit protection in motors, transformers and other loads with high inrush currents, with rated voltages up to 500 VAC (120kA) and 690 VAC (80kA). They offer excellent protection of switchgear (contactor, thermal overloads) due to the good current limiting capability and low I2t values.

RATED CURRENT 125A
RATED VOLTAGE 500V
BREAKING CAPACITY120kA
CLASSaM
FUSE SIZENH00
DESCRIPTIONaM NH motor protection HRC DIN fuse link
CONFORMITY TO STANDARDSIEC/EN 60269-1, IEC/EN 60269-2, DIN 43620

Product Data Sheet

ViewDownload

Instruction Manuals

Request

Certifications

Request

Cad Drawings

Request
