SUL942460
25A 12-280VAC SS RELAY+HEATSINK
R1,363.29
Supplier: Celduc
Pack Size: 1
SUL9 series - Solid state relays (SSR)
All Celduc SSR's (solid state relays) are fitted with back-to-back thyristors and employ 4th generation TMS²technology with a very long life expectancy.
General features:
- Cost-effective, reliable and compact solution (22.5 mm pitch SSR solution)
- Mounting configuration compatible with all standard hockey puck style relays
- Over-voltage protection on input (transil)
- IP20 terminal protection cover (removable)
- Control status LED indication
Complete "ready for use" SSR + heat sink combination
For resistive loads (AC-51) - heating
| SERIES | SUL9 |
| SWITCHING CURRENT | 25A |
| SWITCHING VOLTAGE | 12 - 280 VAC |
| PEAK VOLTAGE | 600V |
| CONTROL VOLTAGE | 3 - 32 VDC |
| DESCRIPTION | Complete solid state relay + heat sink combination |
| INDEX PROTECTION IP | IP20 |
| DIMENSIONS (MM) | (H) 90 x (W) 22.5 x (D) 112 |
