SPN802R
TYPE1+2 100kA 4P 3PH+N SPD+IND
R12,000.00
Supplier: Hager
Supplier Code: SPN802R
Pack Size: 1
Modular surge protection devices
For the protection of low voltage equipment against transient voltages and current surges from atmospheric origins (lightning) as well as transients produced by switching characteristics such as in switching of distribution networks, transformers, motors, etc.
Features:
- Replaceable plug-in cartridges
- Lightning and surge-voltage protection in one device
- Class 1 and class 2 combined surge protection device
| NUMBER OF POLES | 3 Phase + N |
| UP | ‰Â¤ 1.5kV |
| LIMP 10/350 ¼ | 100kA |
| DESCRIPTION | Class 1 + 2 modular surge protection device |
| WIDTH IN 17.5MM | 8 |
| SANS/IEC | 61643-1 |
| CARTRIDGES | Replaceable plug-in cartridges |
| RATED OPERATIONAL VOLTAGE | 230/400 V |
| FREQUENCY | 50/60 Hz |
| OPERATING TEMPERATURE | -40 to 60 °C |
| REMOTE CONTROL | Yes |
| NEUTRAL POSITION | Right |
| APPLICATION | Lighting and surge-voltage protection in one device |
