FSK 250
250A B3 80KA 500VAC TKF FUSE-LINK
R368.43
Supplier: EM
Pack Size: 1
Bolted type HRC fuse links (BS88)
Features:
- Fuse class: gG/Q1
- Central bolted tag (B3)
- Rated voltage: 500 VAC
- Industrial protection HRC fuses
- Rated breaking capacity: 80 kA
- Standards specification: BS88-2, IEC 60269-2-1
| RATED CURRENT | 250A |
| RATED VOLTAGE | 500V |
| BREAKING CAPACITY | 120kA |
| BS88 REFERENCE | B3 |
| DESCRIPTION | Central bolted tag |
| FIXING CENTER (MM) | 111 |
| BODY DIAMETER (MM) | 50.5 |
| BODY LENGTH (MM) | 136 |
| FUSE CLASS | gG/Q1 |
| TYPE (GEC) | TKF |
| CONFORMITY TO STANDARDS | BS88-2, IEC |
