DTK7272R01
DTK TEMP CONTROLLER RELAY O/P
R1,470.09
Supplier: Delta
Pack Size: 1
DTK series "low cost" temperature controller
DTK series is a new temperature controller with a high cost-performance ratio. It greatly decreases development costs a nd time, and improves the functions of temperature control systems. With a length of only 60 mm and high resolution LCD display, it is easy for operators to monitor the temperatures of any environment or occasion.
Features:
- High speed sampling time 100 ms
- PID, ON/OFF, Manual control modes
- 1 alarm output with 9 selectable alarm modes
- Thermocouple: Type (K-J-T-E-N-R-S-B-L-U-TXK)
- Platinum RTD: Pt100, JPt100
- Control method: PID, ON/OFF, Manual control mode
- Speed: High speed sampling time (100ms)
- LCD display: Process Value (PV) Red colour - Set point (SV) Green colour
| SERIES | DTK series |
| SUPPLY VOLTAGE | 100 - 240 VAC |
| FREQUENCY | 50/60 Hz |
| INDEX PROTECTION IP | IP65 |
| PANEL SIZE (MM) - W X H | 72 x 72 |
| THERMOCOUPLE | Type (K-J-T-E-N-R-S-B-L-U-TXK) - Platinum RTD: Pt100, JPt100 |
| DESCRIPTION | Low cost temperature controller |
| LCD DISPLAY | Process Value (PV) Red colour - Set point (SV) Green colour |
| OUPUT 1 | Relay |
