32A 3P+E IP54 SURF SWITCH SOCKET
Industrial switched sockets(interlocked)
Advance 2 series industrial switch sockets(compact version)
SCAME, ADVANCE 2 Series, interlocked socket outlets have smooth and well-connected surfaces, with no sharp edge or lines, included the hand grip, which ensure top safety and ergonomic use as well as easy cleaning, being installed in environments that particularly need such requirement.
- Screwless plate
- Wide room for cabling
- Grip can be locked
- Plate with overprinted window
- Improved mechanical interlocking system.
- Threaded cable inlet with possible in-out device on the bottom
- Very few elements to be assembled for easy and quick installing and maintaining operations.
|INSULATED VOLTAGE||690 VAC|
|OPERATING TEMPERATURE||-25 - +40Â°C (max operating temperature +60Â°C)|
|GLOW WIRE TEST||650/850Â°C|
|MATERIAL||Engineering plastic (halogen free)|
|NUMBER OF POLES||3P+E|
|IMPACT RESISTANCE||IK07 (500g with a striking energy of 2J)|
|INDEX PROTECTION IP||IP44|
|DESCRIPTION||Surface switch socket outlet|
|MECHANICAL INTERLOCKED||Only operates with plug inserted, plug only removable with switch off|
|DIMENSIONS (MM)||(H)256 x (W)106 x (D)129|
