383530
1000A aM DIN NH4 FUSE LINK 500V
R2,884.65
Supplier:
Pack Size: 1
aM (motor protection) fuse links (top indicator)
aM class (NH) for motor protection. These high breaking capacity fuse-links are intended for short circuit protection in motors, transformers and other loads with high inrush currents, with rated voltages up to 500 VAC (120kA) and 690 VAC (80kA). They offer excellent protection of switchgear (contactor, thermal overloads) due to the good current limiting capability and low I2t values.
| RATED CURRENT | 1000A |
| RATED VOLTAGE | 500V |
| BREAKING CAPACITY | 120kA |
| CLASS | aM |
| FUSE SIZE | NH4 |
| DESCRIPTION | aM NH motor protection HRC DIN fuse link |
| CONFORMITY TO STANDARDS | IEC/EN 60269-1, IEC/EN 60269-2, DIN 43620 |
